    Summary Features:

    This series features a unique design integrating automatic residue removal, ultrasonic soaking tank, high-speed washing and drying functions. With an elegant and attractive appearance, the machines deliver stable and reliable performance.


    Our conveyor dishwashers can be customized according to customer requirements. If you have any needs, please feel free to contact us.

    Product Details
    Product Introduction
    This dishwashermachinery.com/Conveyor-Dishwasher/' target='_blank' title='conveyor dishwasher'>conveyor dishwasher is suitable for large staff canteens, schools and catering centers with more than 600 diners.Our company’s conveyor dishwasher is equipped with a dual spraying system. The second stage adopts 360° surround spraying, which effectively reduces water consumption. Double-layer insulation minimizes heat loss and lowers noise. The integrally deep-drawn water tank design ensures hygiene with no dead corners. A photoelectric sensor detects incoming tableware and automatically activates washing and spraying. The integrated flip-up imported protective plate makes cleaning easy. An automatic cleaning system allows internal cleaning of the spray arms without removal. The drying section is equipped with side air outlets for thorough tableware drying. The detergent-saving system directs spray water to the pre-wash tank, reducing detergent consumption. The machine is fitted with start, stop and emergency stop switches at the inlet and outlet for convenient operation. Imported air vents and an outlet exhaust fan are also installed to reduce steam escape.


    This series features a unique design integrating automatic residue removal, ultrasonic soaking tank, high-speed washing and drying functions. With an elegant and attractive appearance, the machines deliver stable and reliable performance.


    The rinsing water temperature reaches over 80°C, guaranteeing excellent washing results and improved efficiency. Built with selected high-quality materials, the dishwasher runs smoothly, requires minimal labor and achieves high output. The cleanliness rate of washed and dried tableware exceeds 99%.


    Through continuous R&D and optimization, the equipment achieves high efficiency and superior quality, reduces breakage caused by manual washing, and lowers tableware costs for the catering industry. It operates at a fast speed with a low failure rate, effectively eliminating users’ concerns about after-sales maintenance.
    Technical Parameter
    ItemR590-MDR590-2MDR590-3MDR590-2M2DR590-3M3D
    ModelR590-MDR590-2MDR590-3MDR590-2M2DR590-3M3D
    Overall Dimensions4300×950×1800 mm5200×950×1800 mm6100×950×1800 mm5900×950×1500 mm7600×950×1800 mm
    Heating MethodElectric / SteamElectric / SteamElectric / SteamElectric / SteamElectric / Steam
    Washing Height420 mm420 mm420 mm420 mm420 mm
    Total Power50.25 kW / 14.25 kW63.75 kW / 15.75 kW69.25 kW / 17.25 kW75 kW / 27 kW88.5 kW / 28.7 kW
    Base Power3.75 kW5.75 kW6 kW6.75 kW7.5 kW
    Main Wash Heating Power12 kW / 0 kW24 kW / 0 kW36 kW / 0 kW24 kW / 0 kW36 kW / 0 kW
    Rinse Heating Power24 kW / 0 kW24 kW / 0 kW24 kW / 0 kW24 kW / 0 kW24 kW / 0 kW
    Dryer Power10.5 kW10.5 kW10.5 kW21 kW21 kW
    Conveyor Speed1–3 m/min1–3 m/min1–3 m/min1–3 m/min1–3 m/min
    Water Consumption280 L/h280 L/h280 L/h280 L/h280 L/h


    Product Features
    1.Ultra-low water consumption greatly reduces the use of electricity, steam, water and detergent, effectively cutting operating costs.
    2.Continuous conveyor washing delivers high efficiency. Tableware can be loaded and unloaded directly, eliminating the need for basket handling and making operation simple.
    3.Washing temperature can be freely adjusted according to different needs. The machine features a high degree of automation and easier maintenance.
